SCtrlFilter
First-Order Lag Filter
Sets the first-order lag filter of the AI terminal of the PID
control module.
Syntax
SCtrlFilter,p1,p2,p3,p4,p5
p1
Unit number
p2
Module number
p3
AI terminal number (AI1, AI2)
p4
Enable or disable (On, Off)
p5
First-order lag constant (0 to 120) Unit:
sec
Query SCtrlFilter[,p1,p2,p3]?
Example Set the first-order lag of AI1 of module number
2 connected to the main unit to 110 (s).
SCtrlFilter,0,2,AI1,On,110
Description
• This command is valid when a PID Control Module is
installed.
SCtrlCalibAI
Calibration Correction
Sets the calibration correction of the AI terminal of the PID
control module.
Disable Calibration Correction
Syntax
SCtrlCalibAI,p1,p2,p3,p4
p1
Unit number
p2
Module number
p3
AI terminal number (AI1, AI2)
p4
Linearizer mode
Off
Correction is not
performed.
Use Calibration Correction (Linearizer approximation,
linearizer bias)
Syntax
SCalibIO,p1,p2,p3,p4,p5,p6,p7,p8,p
9,p10,p11,p12,p13,p14,p15,p16,p17,
p18,p19p,20p,p21,p22,p23,p24,p25,p
26,p27,p28,p29
p1
Unit number
p2
Module number
p3
AI terminal number (AI1, AI2)
p4
Linearizer mode
Appro
Linearizer approximation
Bias
Linearizer bias
p5
Number of segmental points (2 to 12)
p6
Input value of segmental point 1
p7
Output value of segmental point 1
p8
Input value of segmental point 2
p9
Output value of segmental point 2
p10
Input value of segmental point 3 (number
of segmental points ≥ 3)
p11
Output value of segmental point 3
(number of segmental points ≥ 3)
p12
Input value of segmental point 4 (number
of segmental points ≥ 4)
p13
Output value of segmental point 4
(number of segmental points ≥ 4)
p14
Input value of segmental point 5 (number
of segmental points ≥ 5)
p15
Output value of segmental point 5
(number of segmental points ≥ 5)
p16
Input value of segmental point 6 (number
of segmental points ≥ 6)
p17
Output value of segmental point 6
(number of segmental points ≥ 6)
p18
Input value of segmental point 7 (number
of segmental points ≥ 7)
p19
Output value of segmental point 7
(number of segmental points ≥ 7)
p20
Input value of segmental point 8 (number
of segmental points ≥ 8)
p21
Output value of segmental point 8
(number of segmental points ≥ 8)
p22
Input value of segmental point 9 (number
of segmental points ≥ 9)
p23
Output value of segmental point 9
(number of segmental points ≥ 9)
p24
Input value of segmental point 10
(number of segmental points ≥ 10)
p25
Output value of segmental point 10
(number of segmental points ≥ 10)
p26
Input value of segmental point 11
(number of segmental points ≥ 11)
p27
Output value of segmental point 11
(number of segmental points ≥ 11)
p28
Input value of segmental point 12
(number of segmental points ≥ 12)
p29
Output value of segmental point 12
(number of segmental points ≥ 12)
Use Calibration Correction (Correction coefficient)
Syntax
SCtrlCalibAI,p1,p2,p3,p4,p5,p6,p7,
p8,p9,p10,p11,p12,p13,p14,p15,p16,
p17,p18,p19p,20p,p21,p22,p23,p24,p
25,p26,p27,p28,p29,p30,p31,p32,p33
,p34,p35,p36,p37,p38,p39,p40,p41
p1
Unit number
p2
Module number
p3
AI terminal number (AI1, AI2)
p4
Linearizer mode
Correct
Correction Factor
p5
Number of correction points (2 to 12)
p6
Uncorrected value 1
p7
Instrument correction coefficient 1
p8
Sensor correction coefficient 1
p9
Uncorrected value 2
p10
Instrument correction coefficient 2
p11
Sensor correction coefficient 2
p12
Uncorrected value 3 (number of
segmental points ≥ 3)
p13
Instrument correction factor 3 (number of
segmental points ≥ 3)
p14
Sensor correction factor 3 (number of
segmental points ≥ 3)
p15
Uncorrected value 4 (number of
segmental points ≥ 4)
p16
Instrument correction factor 4 (number of
segmental points ≥ 4)
p17
Sensor correction factor 4 (number of
segmental points ≥ 4)
p18
Uncorrected value 5 (number of
segmental points ≥ 5)
2.4 Setting Commands
