13-12 IM 760401-01E
PS/PS? Sets the input as the PLL source/
inquires about the current setting.
Syntax PS m <terminator>
“m” indicates the input as the PLL
source
m= 1: V1
2: A1
3: V2 (for WT230 model 760503
only)
4: A2 (for WT230 model 760503
only)
5: V3 (for WT230 only)
6: A3 (for WT230 only)
Query PS? <terminator>
Example PS1
Description • Parameter error 12 will occur if any illegal
value is set.
• While recalling or storing is in progress,
execution error 19 will occur.
RA/RA? Sets current range/inquires about the
current setting.
Syntax RA m <terminator>
“m” indicates current range.
• When the crest factor is set to 3
m= 4: 0.5 A range
5: 1 A range
6: 2 A range
7: 5 A range
8: 10 A range
9: 20 A range
15: 50 mV range (only when
equipped with option EX2)
16: 100 mV range (only when
equipped with option EX2)
17: 200 mV range (only when
equipped with option EX2)
18: 2.5 V range (only when
equipped with option EX1)
19: 5 V range (only when
equipped with option EX1)
20: 10 V range (only when
equipped with option EX1)
21: 5 mA range (WT210 only)
22: 10 mA range (WT210 only)
23:20 mA range (WT210 only)
24:50 mA range (WT210 only)
25:100 mA range (WT210 only)
26:200 mA range (WT210 only)
• When the crest factor is set to 6
m = 4: 0.25 A range
5: 0.5 A range
6: 1 A range
7: 2.5 A range
8: 5 A range
9: 10 A range
15: 25 mV range (only when
equipped with option /EX2)
16: 50 mV range (only when
equipped with option /EX2)
17: 100 mV range (only when
equipped with option /EX2)
18: 1.25 V range (only when
equipped with option /EX2)
19: 2.5 V range (only when
equipped with option /EX2)
20: 5 V range (only when
equipped with option /EX2)
21: 2.5 mA range (only when
equipped with option /EX2)
22: 5 mA range (WT210 only)
23: 10 mA range (WT210 only)
24: 25 mA range (WT210 only)
25: 50 mA range (WT210 only)
26: 100 mA range (WT210 only)
Query RA? <terminator>
Example RA9
Description • Parameter error 12 will occur if “m” is set to
an illegal value.
• Changing of the current range is not allowed
while integration is in progress; execution
error 13 will occur.
• The 50 mV, 100 mV and 200 mV or 2.5V, 5V
and 10V ranges are for the external sensor.
When using any of these ranges, be sure to
set a valid sensor value using the SA
command.
• While recalling or storing is in progress,
execution error 19 will occur.
RC Initializes setting parameters.
Syntax RC <terminator>
Description For details on initialization, see section 12.2,
“Initializing Setup Parameters.” Setup
parameters excluding those related to
communication are initialized.
RO/RO? Sets the recall function ON/OFF or
inquires about the current setting.
Syntax RO m <terminator>
“m” indicates recall ON or OFF.
m= 0: recall OFF
1: recall ON
Query RO? <terminator>
Example RO1
Description Parameter error 12 will occur if “m” is set to an
illegal value.
RR/RR? Sets the recalling interval/inquires about
the current setting.
Syntax RR m1,m2,m3 <terminator>
“m1” indicates the hours
0 ≤ m1 ≤ 99
“m2” indicates the minutes
0 ≤ m2 ≤ 59
“m3” indicates the seconds
0 ≤ m3 ≤ 59
13.1 Commands
