YOKOGAWA WT210

13-14 IM 760401-01E
• You cannot change the setting while
integration is in progress. Execution error 13
will occur.
• While recalling or storing is in progress,
execution error 19 will occur.
SL Recalls setup parameters from a
selected file.
Syntax SL m <terminator>
“m” indicates file no., and must be
set within the following range.
1 ≤ m ≤ 4
Description • Parameter error 12 will occur if “m” is set to
an illegal value.
• It is not possible to recall communications-
related information (communication mode,
address etc.) using this command.
• While recalling or storing is in progress,
execution error 19 will occur.
SN/SN? Sets the measurement synchronization
source/inquires about the current
setting.
Syntax SN m <terminator>
“m” indicates the type of
measurement synchronization source.
m= 0: V (voltage)
1: A (current)
2: OFF
Query SN? <terminator>
Example SN0
Description • Parameter error 12 will occur if “m” is set to
an illegal value.
• You cannot change the setting while
integration is in progress. Execution error 13
will occur.
• While recalling or storing is in progress,
execution error 19 will occur.
SO/SO? Sets the store function ON/OFF or
inquires about the current setting.
Syntax SO m <terminator>
“m” indicates whether storage is ON
or OFF.
m= 0: OFF
1: ON
Query SO? <terminator>
Example SO1
Description • Parameter error 12 will occur if “m” is set to
an illegal value.
• While recalling or storing is in progress,
execution error 19 will occur.
SR/SR? Sets the storage interval/inquires about
the current setting.
Syntax SR m1,m2,m3 <terminator>
“m1” indicates the hours
0 ≤ m1 ≤ 99
“m2” indicates the minutes
0 ≤ m2 ≤ 59
13.1 Commands
“m3” indicates the seconds
0 ≤ m3 ≤ 59
Query SR? <terminator>
Example SR0,0,0
Description • Parameter error 12 will occur if an illegal
value is set.
• If the store interval is set to 0 h 0 min 0 s, the
store interval is set to the same interval as the
display update rate.
• While recalling or storing is in progress,
execution error 19 will occur.
SS Stores setup parameters into a selected
file.
Syntax SS m <terminator>
“m” indicates file no., and must be
set within the following range.
1 ≤ m ≤ 4
Description • Parameter error 12 will occur if “m” is set to
an illegal value.
• The following setup parameters can be
stored:
All setup parameters which can be output by
the OS command
Information related to communications (GP-
IB, serial, etc.)
TM/TM? Sets integration preset time/inquires
about the current setting.
Syntax TM m1,m2, m3 <terminator>
“m1” indicates the hours
0 ≤ m1 ≤ 1000
“m2” indicates the minutes
0 ≤ m2 ≤ 59
“m3” indicates the seconds
0 ≤ m3 ≤ 59
Query TM? <terminator>
Example TM0,0,0
Description • Parameter error 12 will occur if an illegal
value is set.
• While recalling or storing is in progress,
execution error 19 will occur.
• The maximum time that can be specified is
10000 (hours).
WR/WR? Sets the wiring system/inquires about
the current setting.
Syntax WR m <terminator>
m= 2: 1P3W (for WT230 only)
3: 3P3W (for WT230 only)
4: 3P4W (for WT230 model
760503 only)
5: 3V3A (for WT230 model
760503 only)
Query WR? <terminator>
Example WR2
Description Parameter error 12 will occur if an illegal value
is set.
