Alarms and Countermeasures
Diag/Service→Status Cause Action
Sensor
errors
Sensor1 (Fld dev
stat0-1)
Sensor1 error is
detected.
1. Check Sensor1 for
damage.
2. Check terminal connection.
3. Check cable resistance
value setting. Set double
of the cable resistance
between the sensor and the
device. It is necessary for
2-wire, 3-wire and 4-wire
RTDs/ohms to compensate
cable resistance.
Sensor2 (Fld dev
stat0-2)
Future use N/A
CJC/electronics
sensor (Fld dev
stat0-3)
CJC failure is
detected.
Use CJC connector for
thermocouple measurement.
ADC
errors
ADC
communication (Fld
dev stat1-1)
ADC failure is
detected.
Contact our service.
ADC checksum
(Fld dev stat1-3)
ADC timeout (Fld
dev stat1-4)
Misc.
errors
EEPROM readback
(Fld dev stat2-1)
EEPROM failure is
detected.
Contact our service.
EEPROM integrity
(Fld dev stat2-2)
RAM integrity
(Fld dev stat2-3)
RAM failure is
detected.
ADC initialization
(Fld dev stat2-4)
ADC failure is
detected.
Flash integrity
(Fld dev stat2-6)
Flash ROM failure
is detected.
Software
(Fld dev stat2-7)
Software failure is
detected.
