YOKOGAWA YTA Series User Manual

8-16
IM 01C50C05-01EN
Item
Parameter
name
Descriptions Initial setting
Setup HART Tag Tag number, up to 8
alphanumerical characters
N/A
Long Tag Tag number, up to 32
alphanumerical characters.
N/A
Descriptor Text which can be used by
user in any way. Up to 16
alphanumerical characters
N/A
Message Text which can be used by
user in any way. Up to 32
alphanumerical characters
N/A
Date Date information. MM/DD/
YY. Not incremented. The
date is updated whenever
changing on guration via
conguration tool
N/A
Final assembly
num
Assembly number N/A
Variable
mapping
PV is/SV is/TV
is/FV is
Setting an assignment for
PV/SV/TV/QV
PV=Sensor,
SV=El/CJC,
TV=QV=None
Range
Variables
Range
conguration
Range setting for PV LRV/
PV URV
*1
Units Unit of PV *1
PV LRV/PV
URV
Lower/upper range value to
denes the 0%/100% value
of the measurement
Depend
on range
conguration
Apply values Rerange by actual input N/A
Upper Sensor
Limit/Lower
Sensor Limit
Maximum/minimum values
for range setting
Depend on
sensor setup
Minimum Span PV minimum span
Process
Sensor
→ Sensor
Setup
Sensor
conguration
Sensor type and related
settings.
*1
Error detection Type of sensor errors to
be detected for burnout
operation
broken and
shorted
sensor
Process
Sensor
→ Sensor
Limits
Upper Sensor
Limit/Lower
Sensor Limit
Maximum/minimum values
for the sensor
Depend on
sensor setup
Minimum Span Minimum span of the sensor
