Item
Parameter
name
Descriptions Initial setting
Setup Output
Condition
→ Analog
output
→ Output
range
Set limit =
NAMUR
Setting for loop cur lower
limit = 3.8mA, loop cur upper
limit = 20.5mA
N/A
Output
Condition
→ Analog
output
→ Sensor
Error Values
Error detection Type of sensor errors to
be detected for burnout
operation. (1)No test
performed, (2)broken
sensor, (3)shorted sensor, or
(4)broken & shorted.
broken and
shorted
sensor
Broken Sensor
value
Setting for analog output
value when sensor broken
*1
Shorted
Sensor value
Setting for analog output
value when sensor shorted
3.6mA
NAMUR down Set analog output value to
3.5mA when sensor broken
or shorted
N/A
NAMUR up Set analog output value to
23mA when sensor broken
or shorted
N/A
Output
Condition
→ HART
output
Loop current
mode
Loop current setting at
multidrop
O󰀨
Poll addr Display and setting for
multidrop (0 to 63)
0
Num req
preams
Number of requested
preambles
N/A
Num resp
preams
Number of response
preambles
5
Review Input
Information
List of input variables N/A
Output
Information
List of output variables N/A
Device
Information
review
List of device information N/A
*1: As specied in the order. If not specied, refer to Table 7.2.
