YOKOGAWA YTA610 User Manual

<3. Part Names and Functions>
3-4
IM 01C50G01-01EN
Table 3.4 Parameters List (HART)
Write Mode: RW=read/write, R=read only
Item Indicator Display Write Mode Setting Type Remarks
Tag number TAG RW Character up to 8 characters
Long tag number LNG.TAG RW Character up to 32 characters
PV unit PV.UNIT RW Selection K, °C, °F, °R, mV, ohm, mA, %,
NOUNIT
PV damping time
constant
PV.DAMP RW Digit 0.00 to 100.00 seconds
Sensor 1 type S1.TYPE RW Selection mv, ohm, Pt100, JPt100, Pt200,
Pt500, Pt1000, Cu10, Ni120, TYPE.B,
TYPE.E, TYPE.J, TYPE.K, TYPE.N,
TYPE.R, TYPE.S, TYPE.T, TYPE.L,
TYPE.U, TYPE.W3, TYPE.C, USR.
TBL, NO.CNCT, SMATCH
Sensor 1 wire S1.WIRE RW Selection 2, 3, 4
Sensor 2 type S2.TYPE RW Selection same as sensor1 type
Sensor 2 wire S2.WIRE RW Selection same as sensor1 wire
PV lower range PV LRV RW Digit
PV upper range PV URV RW Digit
Sensor burnout
direction
BUN.DIR RW Selection HIGH, LOW, USER, OFF
Sensor burnout value
(mA)
BUN mA RW Digit 3.6 to 21.6 mA
Sensor burnout value
(%)
BUN % RW Digit -2.5 to 110%
Display out 1 DISP.1 RW Selection SENS.1, S.1-TER., TERM, SENS.2,
S.2 - TER., S.1 - S.2, S2 - S.1, AVG,
BACKUP, PV, SV, TV, QV, OUT %,
OUT.mA
Write protect WRT.PRT RW Selection ON, OFF
Model MODEL R ─
HART revision HART R ─
Device revision DEV.REV R ─
Software revision SW.REV R ─
Table 3.5 Parameters List (FF)
Write Mode: RW=read/write, R=read only
Item Indicator Display Write Mode Setting Type Remarks
PD TAG PD.TAG R ─
Disp Out 1 DISP.1 RW Selection SENS.1, S.1-TER., TERM, SENS.2,
S.2 - TER., S.1 - S.2, S2 - S.1, AVG,
BACKUP, AI1.OUT, AI2.OUT, AI3.OUT,
AI4.OUT
Local Write Lock HW.LOCK RW Character Up to 8 Character, OFF
Simulation HW SIM RW Selection ON, OFF
Model MODEL R ─
Dev Rev DEV.REV. R ─
Software Rev SW.REV R ─
