YOKOGAWA YTA610 User Manual

<3. Part Names and Functions>
3-6
IM 01C50G01-01EN
3.4.2 ParametersConguration
(1) Activating Local Parameter Setting
Push the ▲ or ▼ button on the integral indicator
to activate the local parameter setting mode. The
transmitter will exit automatically from the local
parameter setting mode if no operation is carried
out for 10 minutes.
(2) Parameter Setting Review (HART and
BRAIN)
Process measurement display
Push ▼ button ↓
TAG
Push ▼ button ↓
LNG.TAG
*1
Push ▼ button ↓
PV.UNIT
Push ▼ button ↓
PV.DAMP
Push ▼ button ↓
S1.TYPE
Push ▼ button ↓
S1.WIRE
Push ▼ button ↓
S2.TYPE
Push ▼ button ↓
S2.WIRE
Push ▼ button ↓
PV LRV
Push ▼ button ↓
PV URV
Push ▼ button ↓
BUN.DIR
Push ▼ button ↓
BUN mA
Push ▼ button ↓
BUN %
Push ▼ button ↓
DISP.1
Push ▼ button ↓
WRT.PRT
Push ▼ button ↓
MODEL
Push ▼ button ↓
HART
*1
Push ▼ button ↓
DEV.REV.
*1
Push ▼ button ↓
SW.REV
Push ▼ button ↓
Process measurement display
*1: Applicable only for HART.
(3) TagNumber(TAG)Conguration
TAG → Push SET button → Change the rst
character by pushing ▲/▼ button → Push SET
button to go to the second character → Change the
second character by pushing ▲/▼ button → Set
all other characters in the same way → Hold down
the SET button → “SAVE?” → Push SET button →
“SAVED”
Push ▲/▼ to return to the process measurement
display.
See “(2) Parameter Setting Review”.
(4) PVUnit(PV.UNIT)Conguration
PV unit (unit of sensor mapping in PV) for the
Table3.4 can be changed as below
PV.UNIT → Push SET button → Select the
temperature unit by pushing ▲/▼ button → Push
SET button → “SAVE?” → Push SET button →
“SAVED”
Push ▲/▼ to return to the process measurement
display.
See “(2) Parameter Setting Review”.
(5) Damping Time Constant (PV.DAMP)
Conguration(HART)
The damping time constant for the amplier
assembly can be set from 0 to 100 seconds.
Damping time constant is rounded off to two
decimal places.
PV.DAMP → Push SET button → Change the rst
digit by pushing ▲/▼ button → Push SET button
to go to the second digit → Change the second
gure by pushing ▲/▼ button → Set all other digits
in the same way → Hold down the SET button →
“SAVE?” → Push SET button → “SAVED”
Push ▲/▼ to return to the process measurement
display.
See “(2) Parameter Setting Review”.
Available numbers
Number
of digits
Selection Remarks
1 0, 1, 2, 3, 4, 5, 6,
7, 8, 9, -9, -8, -7,
-6, -5, -4, -3, -2,
-1, -0
Determine plus and minus
in the rst digit. Return
cannot be selected. In
case of integer a minus
cannot be selected.
2 to 5 0, 1, 2, 3, 4, 5, 6,
7, 8, 9, Dot(.), r*
A dot uses a one digit.
Two dots cannot use.
In case of integer a dot
cannot be selected.
6 0, 1, 2, 3, 4, 5, 6,
7, 8, 9, Dot(.), r*
A dot cannot use in 6th
digits.
*: Press the SET button at the time of r display, one digit will
return.
