<3. Part Names and Functions>
3-5
IM 01C50G01-01EN
Table 3.6 Parameters List (BRAIN)
Write Mode: RW=read/write, R=read only
Item Indicator Display Write Mode Setting Type Remarks
Tag number TAG RW Character up to 16 characters
PV unit PV.UNIT RW Selection K, °C, °F, °R, mV, ohms, mA, %,
NOUNIT
PV damping time
constant
PV.DAMP RW Selection 0,1,2,...,100 seconds
Sensor 1 type S1.TYPE RW Selection TYPE.B, TYPE.E, TYPE.J, TYPE.K,
TYPE.N, TYPE.R, TYPE.S, TYPE.T,
TYPE.C, TYPE.W3, TYPE.L, TYPE.U,
Pt100, Pt200, Pt500, Pt1000, JPt100,
Ni120, Cu10, S.MATCH, ohms, mV,
NO.CNCT
Sensor 1 wire S1.WIRE RW Selection 2, 3, 4
Sensor 2 type S2.TYPE RW Selection same as sensor1 type
Sensor 2 wire S2.WIRE RW Selection same as sensor1 wire
PV lower range PV LRV RW Digit
PV upper range PV URV RW Digit
Sensor burnout
direction
BUN.DIR RW Selection HIGH, LOW, USER, OFF
Sensor burnout value
(mA)
BUN mA RW Digit 3.6 to 21.6 mA
Sensor burnout value
(%)
BUN % RW Digit -2.5 to 110%
Display out 1 DISP.1 RW Selection PV, SV, TV, QV
Write protect WRT.PRT RW Selection ON, OFF
Model MODEL R ─
Software revision SW.REV R ─
