  <2.Specications>
2-7
IM 11M12G01-02EN 1sh Edition : Mar. 25, 2021-00
l EXTERNAL DIMENSIONS
1. Model ZR22G Separate type Zirconia Oxygen/Humidity Analyzer, Detectors
25
t
283 to 292
Ø50.8
Ø124
±3
85
L
48
155 to 163 69
ØB
ØA
C
F2-1E.ai
L=0.15, 0.4, 0.7, 1.0,
1.5, 2.0, 2.5, 3.0
3.6, 4.2, 4.8, 5.4 (m)
Rc1/4 or 1/4NPT
Reference gas inlet
2-G1/2,2-1/2NPT etc.
Cable connection port
Rc1/4 or 1/4NPT
Calibration gas inlet
Flange
Flange
Flange
ØB
ØA
C
Unit : mm
Flange
ANSI Class 150 2 RF
ANSI Class 150 3 RF
ANSI Class 150 4 RF
DIN PN10 DN50 A
DIN PN10 DN80 A
DIN PN10 DN100 A
JIS 5K 65 FF
JIS 10K 65 FF
JIS 10K 80 FF
JIS 10K 100 FF
JIS 5K 32 FF
JPI Class 150 4 RF
JPI Class 150 3 RF
Westinghouse
152.4
190.5
228.6
165
200
220
155
175
185
210
115
229
190
155
120.6
152.4
190.5
125
160
180
130
140
150
175
90
190.5
152.4
127
4 - Ø19
4 - Ø19
8 - Ø19
4 - Ø18
8 - Ø18
8 - Ø18
4 - Ø15
4 - Ø19
8 - Ø19
8 - Ø19
4 - Ø15
8 - Ø19
4 - Ø19
4 - Ø11.5
A B C
19
24
24
18
20
20
14
18
18
18
5
24
24
14
t
