<2.Specications>
2-6
IM 11M12G01-02EN 1sh Edition : Mar. 25, 2021-00
l Model and Codes
Style : S2
Model Sux code Option code Description
ZR22G - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Zirconia Oxygen/Humidity Analyzer, Detector
Length -015
-040
-070
-100
-150
-200
-250
-300
-360
-420
-480
-540
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
0.15 m (for high temperature use) (*1)
0.4 m
0.7 m
1.0 m
1.5 m
2.0 m
2.5 m (*2)
3.0 m (*2)
3.6 m (*2)
4.2 m (*2)
4.8 m (*2)
5.4 m (*2)
Wetted material -S
-C
- - - - - - - - - -
- - - - - - - - - -
Stainless steel
Stainless steel with Inconel calibration gas tube (*10)
Flange
(*3)
-A
-B
-C
-E
-F
-G
-K
-L
-M
-P
-Q
-R
-S
-W
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
ANSI Class 150 2 RF
ANSI Class 150 3 RF
ANSI Class 150 4 RF
DIN PN10 DN50 A
DIN PN10 DN80 A
DIN PN10 DN100 A
JIS 5K 65 FF
JIS 10K 65 FF
JIS 10K 80 FF
JIS 10K 100 FF
JIS 5K 32 FF (for high temperature use) (*4)
JPI Class 150 4 RF
JPI Class 150 3 RF
Westinghouse
Reference gas -C
-E
-P
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
Natural convection
External connection (Instrument air) (*11)
Pressure compensated (*11)
Gas Thread -R
-T
- - - - - - - - - -
- - - - - - - - - -
Rc1/4
1/4NPT(Female)
Connection box thread -P
-G
-M
-T
-Q
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
G1/2
Pg13.5
M20 x1.5
1/2 NPT
Quick connect (*9)
Instruction manual -J
-E
-C
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
Japanese
English
Chinese
-- -A - - - - - - - - - - Always -A
Options /C Inconel bolt (*5)
Valves /CV
/SV
Check valve (*6)
Stop valve (*6)
Filter /F1
/F2
Dust Filter (*7)
Dust Guard Protector (*7)
Tag plates /SCT
/PT
Stainless steel tag plate (*8)
Printed tag plate (*8)
Standard /EQ
/ER
EAC with PA (*12)
EAC (*12)
*2 When installing horizontally the probe whose insertion length is 2.5 m or more, use the Probe Protector. Be sure to
*5 Inconel probe bolts and U shape pipe are used. Use this option for high temperature use (ranging from 600 to 700 °C).
*6 Specify either /CV or /SV option code.
*7 Not used with the high temperature humidity analyzer.
*8 Specify either /SCT or /PT option code.
*9 Not waterproof, avoid rain. Operating maximum temperature is 80°C. Available only in the U.S.
*10 Recommended if sample gas contains corrosive gas like chlorine.
*12 “/EQ” is EAC with Pattern Approval for Russia. “/ER” is EAC for Kazakhstan and Belarus.
To Next Page
