FIGURE 55 - SAMPLE PRINTOUT (STATUS) (CONT’D)
Steam Control
-------------------------------------------------------
Inlet Temperature = 358.9 ~F
Inlet Pressure = 136.0 Psig
First Stage Pressure = 41.2 Psig
Exhaust Pressure = 1.5 Psia
Inlet Solenoid = Off
Inlet Valve = 0 %
Bypass Solenoid = Off
Inlet Limit Switch = Closed
Slow Roll Valve = 0 %
Turbine Vibration Sensor
-------------------------------------------------------
Governor End Horizontal Vibration = 0.5 Mils
Governor End Vertical Vibration = 0.5 Mils
Shaft End Horizontal Vibration = 0.5 Mils
Shaft End Vertical Vibration = 0.5 Mils
Turbine Solenoids
-------------------------------------------------------
Turbine Rotation = Open
Trip Solenoid = Off
Trip Valve Limit Switch = Open
Vacuum Solenoid = Off
Inlet Limit Switch = Closed
Oil Cooler Solenoid = Off
Gland Solenoid = Off
Nozzle #1 Solenoid = Off
Nozzle #2 Solenoid = Off
Steam Ring Drain Solenoid = On
Condensate Drain Tank High Level Switch = Closed
Turbine Oil / Bearings
--------------------------------------------------------
Oil Temperature = 110.5 ~F
Oil Pressure = 18.1 Psig
Governor End Bearing Temperature = 170.1 ~F
Shaft End Bearing Temperature = 149.5 ~F
Aux Oil Pump Run Output = Off
Aux Oil Pump Contact = Open
Aux Oil Pump Manual Mode = Disabled
Hotwell Level
--------------------------------------------------------
HLSP1 - Hotwell Condensate Level = 50.0 %
Condensate Level = 50.4 %
Hotwell Level Control Output Signal = 49.6 %
Pump #1 Run Output = Off
Pump #1 Aux Contact = Open
Pump #2 Run Output = Off
Pump #2 Aux Contact = Open
Low Level Switch = Closed
High Level Switch = Closed
Hotwell Level Control Auto/Manual Mode = Auto
Vacuum System
--------------------------------------------------------
Pump #1 Run Output = Off
Pump #1 Aux Contact = Open
Pump #1 Sealing Water Solenoid = Off
Pump #1 Sealing Water Flow Switch = Open
Pump #2 Run Output = Off
Pump #2 Aux Contact = Open
Pump #2 Sealing Water Solenoid = Off
Pump #2 Sealing Water Flow Switch = Open
Ejector Actuator = Off
Flow Sensor
--------------------------------------------------------
Evaporator Flow = 2628 Gal/Min
Condenser Flow = 4312 Gal/Min
Steam Flow = 14496 Lb/Hr
To Next Page
