Technical Specifications
188
Buttons Programmable back button; dual dedicated scan buttons;
dedicated push-to-talk button, and volume up/down buttons
Performance Characteristics
CPU Qualcomm Snapdragon 660 octa-core, 2.2 GHz.
Operating System Android 8.1 Oreo with Zebra’s Restricted Mode for control over
GMS and other services.
Memory 4 GB RAM/32 GB Flash
Output Power USB - 5 VDC @ 500 mA max
User Environment
Operating Temperature -20°C to 50°C (-4°F to 122°F)
Relative Humidity Operating: 5 to 95% non-condensing
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Charging Temperature 0° C to 40° C (32°F to 104°F)
Humidity 5 to 85% non-condensing
Drop Specification Multiple 1.2 m (4 ft.) to tile over concrete over -10°C to 50°C
(14°F to 122°F).
Multiple 1.8 m (6 ft.) drops to concrete with Rugged Boot per Mil
Std 810 G.
Tumble 500 0.5 m (1.6 ft.) tumbles; meets and exceeds IEC tumble
specifications
Sealing IP67 and IP65 per applicable IEC sealing specifications
Electrostatic Discharge (ESD) ±15 kVDC air discharge, ±8 kVDC direct discharge, ± 8 kVDC
indirect discharge
Vibration 4 g’s PK Sine (5 Hz to 2 kHz); 0.04g2/Hz Random (20 Hz to
2 kHz); 60 minute duration per axis, 3 axis
Thermal Shock -40°C to 70°C (-40°F to 158°F) rapid transition
Interactive Sensor Technology (IST)
Motion Sensor 3-axis accelerometer with MEMS Gyro
Light Sensor Automatically adjusts display backlight brightness
Proximity Sensor Automatically detects when the user places the handset against
head during a phone call to disable display output and touch
input.
Pressure Sensor Automatically detects altitude information for locationing.
Magnetometer eCompass automatically detects direction and orientation.
Wireless LAN Data and Voice Communications
Radio IEEE 802.11a/b/g/n/ac/d/h/i/k/r/v/w; Wi-Ficertified; IPv4, IPv6;
2X2 MU-MIMO
Data Rates Supported 5GHz: 802.11a/n/ac - up to 866.7 Mbps
2.4GHz: 802.11b/g/n - up to 300 Mbps
Table 17 TC52 Technical Specifications (Continued)
Item Description

Table of Contents

Other manuals for Zebra TC52

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zebra TC52 and is the answer not in the manual?

Zebra TC52 Specifications

General IconGeneral
RFID reader-
Scanner type2D
Product colorBlack
Phone functionYes
Display diagonal5 \
Touch technologyDual-touch
Touchscreen typeCapacitive
Display resolution1280 x 720 pixels
USB 2.0 ports quantity1
Flash memory32 GB
Internal memory4 GB
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size256 GB
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)-20 - 50 °C
Operating relative humidity (H-H)5 - 95 %
Battery capacity4150 mAh
Number of cores8
Processor model660
Processor familySnapdragon
Processor frequency2.2 GHz
Processor manufacturerQualcomm
GPS (satellite)No
Operating system installedAndroid
Bluetooth version5.0
Rear camera aperture number2.2
Front camera aperture number2
Rear camera resolution (numeric)13 MP
Front camera resolution (numeric)5 MP
Weight and Dimensions IconWeight and Dimensions
Depth18.6 mm
Width75.5 mm
Height155 mm
Weight249 g
