Technical Specifications
189
Operating Channels Chan 1 - 13 (2412 - 2472 MHz)
Chan 36 - 165 (5180 - 5825 MHz)
Channel Bandwidth: 20, 40, 80 MHz
Actual operating channels/frequencies depend on regulatory
rules and certification agency
Security and Encryption WEP (40 or 104 bit); WPA/WPA2 Personal (TKIP, and AES);
WPA/WPA2 Enterprise (TKIP and AES) — EAP-TTLS (PAP,
MSCHAP, MSCHAPv2), EAP-TLS, EAP-PEAPv0-MSCHAPv2,
EAP-PEAPv1-GTC, EAP-LEAP, EAP-PWD.
Data in Motion: FIPS 140-2 Level 1
Data at Rest: FIPS 140-2 Level 1
Certifications WFA (802.11n, WMM-PS, 802.11r; PMF)
Fast Roam PMKID caching; Cisco CCKM; 802.11r; OKC
Wireless PAN Data and Voice Communications
Bluetooth Class 2, Bluetooth v5.0, Bluetooth Low Energy (BLE)
Data Capture Specifications
Scanning SE4710 imager (1D and 2D) with LED aimer. Digimarc support.
Camera Front — 5 MP; f/2.0 aperture front facing camera.
Rear — 13 MP autofocus; f/2.2 aperture; rear camera flash LED
generates balanced white light; supports Torch mode; 4K video
with image stabilization.
Near Field Communications
(NFC)
ISO 14443 Type A and B; F; FeliCa and ISO 15693 cards; P2P
mode and Card Emulation via Host
2D Imager Engine (SE4710) Specifications
Field of View Horizontal - 48.0°
Vertical - 36.7°
Image Resolution 1280 horizontal X 960 vertical pixels
Roll 360°
Pitch Angle ± 60° from normal
Skew Tolerance ± 60° from normal
Ambient Light Sunlight: 10,000 ft. candles (107,639 lux)
Focal Distance From front of engine: 17.7 cm (7.0 in.)
Laser Aiming Element Visible Laser Diode (VLD): 655 nm ± 10 nm
Central Dot Optical Power: 0.6 mW (typical)
Pattern Angle: 48.0º horizontal, 38.0º vertical
Illumination System LEDs: Warm white LED
Pattern Angle: 80° at 505 intensity
Table 17 TC52 Technical Specifications (Continued)
Item Description
