Accessories
139
4.
Hang the bracket on the screws.
5. Install two top screws.
6. Tighten all screws.
7. Assembly the top tray. See steps 6 through 8 on page 129.
8. Slide the assembled top tray onto bottom tray.
9. Connect cables to cradle.
10. Secure top tray to bottom tray with four M5 screws (two on each side).
11. Route cables and connect to power source.
