Getting Started
16
Figure 2 Rear View
Setting up the Device
To start using the device for the first time:
1. Install wrist mount (optional).
2. Install the battery.
3. Charge the device.
4. Power on the device.
Number Item Function
16 Cleat Provides alignment and secures the device to the wrist
mount.
17 Left interface
connector
Provides USB host and client communication, audio and
device charging via cables and accessories.
17
16
