Zebra ZQ220 User Manual

2
ZQ220 User Guide
Contents
Proprietary Statements ...................................................... 5
Document Conventions ..................................................... 7
Introduction to the ZQ220 Printer ..................................... 8
Unpacking and Inspection ..................................................................9
Reporting Damage .............................................................................9
ZQ220 Technology ...........................................................................10
Battery ............................................................................................. 10
QR Code .......................................................................................... 11
Made for iPhone (MFi) .....................................................................12
Near Field Communication (NFC) ....................................................12
Printer Overview ............................................................... 13
Getting Ready to Print ...................................................... 15
Battery .............................................................................................. 15
Removing the Battery ......................................................................15
Removing the Battery Tape Insulator ...............................................16
Installing the Battery ........................................................................17
Battery Safety ..................................................................................18
Charger Safety .................................................................................18
Charging the Battery ........................................................................19
AC-to-USB Charger ........................................................................19
Loading Media Procedure ................................................................ 21
Operator Controls ............................................................................23
Standard User Controls ...................................................................23
LCD Control Panel ...........................................................................23

Zebra ZQ220 Specifications

General

Color	No
Print technology	Direct thermal
Rotated printing	Yes
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Minimum print length	12.5 mm
Maximum printing width	80 mm
Internal memory	16 MB
Number of fonts	14
Built-in barcodes	2D, Code 39, Code 93, Code-39 Library, EAN128, EAN13, EAN8, UPC-A, UPC-E
Battery type	Built-in battery
Battery voltage	7.26 V
Number of batteries supported	1
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Core diameter	22.2 mm
Media thickness	0.058 - 0.1575 mm
Maximum label width	72 mm
Maximum roll diameter	50 mm
Bluetooth version	2.1+EDR
Connectivity technology	Wireless
Display	-
Product color	Black
Display diagonal	3 \
Quantity per pack	1 pc(s)
Languages support	ENG, RUS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	58.8 mm
Width	114.5 mm
Height	129.5 mm
Weight	450 g
