Zebra ZQ220 User Manual

33
ZQ220 User Guide
Note • For detailed information on Bluetooth, please refer
to the Bluetooth Wireless User Guide (P1068791-002) at:
http://www.zebra.com/us/en/support-downloads.html
In addition, the printers support a “scan and pair” function via a
handheld device and the MAC Address label on the bottom of the
printer (see “Figure 8 • BT Communications” on page 33). The
ZQ220 printer also features passive Near Field Communication
(NFC) technology. Using the “Print Touch” feature located on the
side of the printer, end users can automatically pair with a handheld
device that supports NFC technology. The NFC tag has the printer’s
BDADDR encoded in a URL on the tag. Simply touching the NFC
handheld device to the “Print Touch” icon on the printer will connect
and pair the handheld device to the printer.
Figure 8 • BT Communications
AC00a0f8a10a26

Zebra ZQ220 Specifications

General

Color	No
Print technology	Direct thermal
Rotated printing	Yes
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Minimum print length	12.5 mm
Maximum printing width	80 mm
Internal memory	16 MB
Number of fonts	14
Built-in barcodes	2D, Code 39, Code 93, Code-39 Library, EAN128, EAN13, EAN8, UPC-A, UPC-E
Battery type	Built-in battery
Battery voltage	7.26 V
Number of batteries supported	1
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Core diameter	22.2 mm
Media thickness	0.058 - 0.1575 mm
Maximum label width	72 mm
Maximum roll diameter	50 mm
Bluetooth version	2.1+EDR
Connectivity technology	Wireless
Display	-
Product color	Black
Display diagonal	3 \
Quantity per pack	1 pc(s)
Languages support	ENG, RUS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	58.8 mm
Width	114.5 mm
Height	129.5 mm
Weight	450 g
