ZQ220 User Guide
Information Screen
The Information Screen is displayed when text must be used to
convey information to the user. The display is split into two viewing
areas: The top portion will display the same icons previously
described on the Operation Screen; the bottom portion will display
text messages. There are two (2) types of messages that can be
displayed on the Information Screen as described below.
1. Timed Messages: These messages will appear for a specic
period of time, and then be removed. For example, after
powering up the printer and the printer is ready to print, the
message “PRINTER READY” will appear for 30 seconds.
2. User Activity Messages: These messages require that the user
performs a needed action. For example, when the printer is out
of media, a “MEDIA OUT” message will be displayed until new
media is loaded in the printer.
PRINTER READY
ZQ220
MEDIA OUT
ZQ220

Zebra ZQ220 Specifications

General

Color	No
Print technology	Direct thermal
Rotated printing	Yes
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Minimum print length	12.5 mm
Maximum printing width	80 mm
Internal memory	16 MB
Number of fonts	14
Built-in barcodes	2D, Code 39, Code 93, Code-39 Library, EAN128, EAN13, EAN8, UPC-A, UPC-E
Battery type	Built-in battery
Battery voltage	7.26 V
Number of batteries supported	1
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Core diameter	22.2 mm
Media thickness	0.058 - 0.1575 mm
Maximum label width	72 mm
Maximum roll diameter	50 mm
Bluetooth version	2.1+EDR
Connectivity technology	Wireless
Display	-
Product color	Black
Display diagonal	3 \
Quantity per pack	1 pc(s)
Languages support	ENG, RUS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	58.8 mm
Width	114.5 mm
Height	129.5 mm
Weight	450 g
