3 Product and Functional Description | 3.1 Main Components of Axiovert 5 digital
3
.1 Main Components of Axiovert 5 digital
Purpose This section shows the main components of Axiovert 5 digital.
3
4
5
6
7
8
1
2
Fig. 2: Main components
1
3
Specimen stage [} 22]
2
4
Stand
Carrier transmitted-light illumination
with white LED 10W
Holder for tablet
5
7
Nosepiece with objectives [} 21]
6
8
Mounting frame M
Object guide
Reflector turret [} 23]
