Zeiss Axiovert 5 digital - Controls and Functional Elements on Components

3
Product and Functional Description | 3.2 Controls and Functional Elements on Components
ZEISS
3
.2 Controls and Functional Elements on Components
3
.2.1 Front Side of the Stand
This section shows the functional components and controls.
1
2
3
4
5
8
7
6
1
3
Anti-theft device
2
4
Condenser
Power switch On/Off with power indi-
cator [} 20]
Coaxial knurled knob for Y adjust-
ment
5
7
Coaxial knurled knob for X adjust-
ment
6
8
Focusing drive – fine adjustment
Focusing drive – coarse adjustment
Snap button (right and left side)
1
8
Instruction Manual ZEISS Axiovert 5 digital | en-US | Rev. 1 | 431030-7021-101
