10 Accessories and Optional System Expansions | 10.1 Assembling the Wi-Fi Dongle
Name
Description/info
Aqua stop
The aqua stop protects the objectives and the nosepiece when
working with liquid samples.
1
0.1 Assembling the Wi-Fi Dongle
Info
The Wi-Fi dongle is an independent item and if it is applicable in the region, it needs to be or-
dered separately.
Hex Key, 3.0 mm
Parts and Tools
Procedure 1. Loosen the screw on the cover.
2. Push the cover to the right and lift it up.
3
. Plug the Wi-Fi dongle into the USB port.
4
5
. Install the cover.
. Tighten the screw.
Instruction Manual ZEISS Axiovert 5 digital | en-US | Rev. 1 | 431030-7021-101
49
