INTRODUCTION Stereo microscope
ZEISS Notes on instrument safety Stemi 508
10 435064-7044-001 01/2015
If it is intended to operate the Stemi 508 with an external fibre optical cold light source, please
refer to the appropriate operating instructions incl. the safety provisions contained in them
before commissioning the light source.
The desktop power unit must not get into contact with moisture.
For transport over an extended distance, the device must be dismantled partially and
transported in its original packaging.
To transport the device over an extended distance, use the original packaging or the transport
case Stemi 305/508.
To connect the LED illuminators of the Stemi 305 system, six-pin modular connectors are used
which are known from telecommunications (type: RJ 12).
Only the LED illuminators pertaining to the Stemi 305 may be connected to the RJ 12 sockets in
the microscope body and in the stands of the Stemi
305. Only the connection cables supplied
with the device may be used.
The use of commercially available cables with RJ 12 connectors or the connection of fax units,
modems or other telecommunication equipment to the RJ 12 sockets of the Stemi
prohibited.
Fig. 1 Warning and information labels on the device
