Zeiss Stemi 508 - Opening the Stand Cover Plate, Stand K EDU

Stere
o microscope CARE, MAINTENANCE AND SERVICE
Stemi 508 Maintenance ZEISS
01/2015 435064-7044-001 37
5.2.2 Opening the stand cover plate,
stand K EDU
The stand cover plate (Fig. 23/1) may be removed
for cleaning or to remove any foreign matter which
might have fallen in inadvertently.
• To this effect, release the three recessed head
screws (Fig. 23/2), lift off the stand cover plate
(Fig. 23/1) carefully and then put it aside.
• Make sure that the cable is not disconnected
from the stand cover plate (Fig. 23/1).
To clean the LED board, use a soft lint-
free cloth, a cotton wool bud wound
around a round wooden stick or a brush
with natural bristles, possibly moistened
slightly in distilled water.
Fig. 23 Opening the stand cover plate,
stand K EDU
