Zendure Hub 2000 User Manual

2
Name Hub 2000
Model ZDHUB2000
Weight ≈ 5.2 kg
Dimensions（L*W*H） 363×246×64 mm
Wireless Type Bluetooth, 2.4GHz & 5GHz Wi-Fi
IP Level IP65
Warranty 10 Years
PV Input
Recommended Input Power 1200 W each
Maximum Input DC Voltage 60V
MPPT Voltage Range 16-60V
MPPT Full Power Voltage Range 35-60V
Min DC Input Voltage 16V
Max Input Current 2*26A
Number of MPPT 2
Output to Microinverter
Recommended Microinverter's Power 400-1200W
Rated Output Power 1200W
Max Microinverter Output Power 1200W
Rated Output Current 30A
Nominal Voltage Range 16-60V
Efciency
Output Efciency 98%
MPPT Tracking Efciency 99%
Working Temperature (° C) -20-45℃
Input from AB2000
Max Input Power 1200 W
Max Input Current 25 A
Rate Voltage 48 V
Output to AB2000
Max Input Power 1200W / 1800W(
≥
2*AB2000)
Max Input Current 25A / 37.5A(
≥
2*AB2000)
Voltage Range 42-54.75V
Input from AB1000
Max Input Power 1200W
Max Input Current 25A
Rate Voltage 48V
Output to AB1000
Max Input Power 800W
Max Input Current 16.6A
Voltage Range 42-54.75V
Input from SuperBase V or Satellite Battery
Max Input Power 1200W
Max Input Current 25A
Voltage Range 45-58.4V
EN

Zendure Hub 2000 Specifications

General

Brand	Zendure
Model	Hub 2000
Category	Switch
Language	English
