Smart Connect Single Loop Touch Screen Panel
Doc: GLT-229-7-1 56
Issue: 3
Date: 12/05/2017
When there are more than 4 slices programmed, the panel
displays up /down scroll arrows in order to view
the other slices
To edit a slice, tap that slice so that it is highlighted yellow, then
press the delete icon .
Press the add icon to add a replacement slice if required.
When finished, press the exit icon . The panel will ask if
you want to save the changes.
Press tick to save the changes, or press to discard.
8.3.2 Setting Day-time and Night-time delays
The day and night time delays are set through the cause and effect programming.
Enter the required cause (as described in section 8.1)
When the panel asks for the output effect, enter the day time
delay in the first delay field. The delay is entered in seconds.
The maximum delay is 600 seconds (10 minutes).
If no night time delay is needed, set the night time delay to Zero
in the second field.
