Zeta SmartConnect - EN 54 Part 2 Functions; Access Levels Explained

Smart Connect Single Loop Touch Screen Panel
Doc: GLT-229-7-1 7
Issue: 3
Date: 12/05/2017
2.1 FUNCTIONS REQUIRED BY EUROPEAN STANDARD EN 54 PART 2
The Smart Connect fire alarm control panel provides the following mandatory and optional functions as prescribed by the European
standard EN 54 Part 2.
(a) Mandatory Functions
The mandatory functions and corresponding indications provided by this panel are:
 fire alarm condition
 fault warning condition
 disablement condition
 quiescent condition (when the CIE is powered by a power supply conforming to EN 54-4 and no other functional condition
is indicated)
(b) Optional Functions (Options with Requirements)
The options with requirements provided by this panel are:
 Clause 7.8 - output to fire alarm devices (i.e. sounders)
 Clause 7.11 - delays to outputs
 Clause 7.12 – Dependencies on More than one alarm signal (Type C)
 Clause 8.3 - fault signals from points
 Clause 9.5 - disablement of addressable points
 Clause 10 – test Condition
(c) Other Functions outside EN54
USB Port (For PC configuration)
RS484 Network / Repeater connection
TCP/IP (Ethernet) connection (Remote access)
NB the terms 'device' and 'point' are used interchangeably throughout this manual.
2.2 EXPLANATION OF ACCESS LEVELS
The Smart Connect System has the following access levels.
ACCESS LEVEL
ACCESSED BY
ACCESS METHOD
FUNCTIONS ACCESSED
1
General public
Default state
View Panel
Override delay (if used)
2a
Responsible person
Enter user access code
(default 0001)
Start sounders
stop sounders
Silence buzzer
Reset panel
Access User Menu
2b
Responsible person
Enter user access code
(default 0001), and press
Menu Access Icon
Enable / disable sections of system
Test Mode
View Zones / Points
View event log
Turn off delay
3a
Installer / Engineer
Enter Engineer Password
(Default 9999), and press
Menu Access Icon
Configure loops
Assign zones
Assign Text to each point
Modify Alarm Operation Programming
Configure network (if fitted)
System Diagnostics (LED blink / loop Autocheck)
Change passwords
Configure TCP/IP Port
3b
Installer / Engineer
Open Enclosure
Connect wiring during Install
Battery check during Maintenance
Update Cause & Effect programming via USB
4
Authorised Service Engineer
Open Enclosure & PC S/W
Update Panel Firmware, Add new language
Care should be taken to ensure that the access method for each level is only available to suitably qualified personnel.
