Zeta SmartConnect - Indication of Day; Night Mode

Smart Connect Single Loop Touch Screen Panel
Doc: GLT-229-7-1 58
Issue: 3
Date: 12/05/2017
The HEAT A1S: Heat detector and HEAT CS: Heat detector
sensor can be set to Off or ON.
8.3.4 Indication of Day / Night Mode
The panel indicates its current operating mode by means of a vertical bar in the top left corner of the LCD.
No Day / Night timer set.
No bar in top left corner.
Day / Night timer set. Panel in Day Mode.
White bar in top left corner.
Day / Night timer set. Panel in Night Mode.
Black bar in top left corner.
