ZF AV 110 - Page 19

Figure Order no.
Designation
Chap
ter/section
Quantit
y
Comment
AA00.844.345
Load r
ing
▪
Remove left portal drive, page 48
▪
Remove right portal drive,
page 58
▪
Setting backlash and differential
bearing rolling torque and checking
axial run-out and contact pattern.,
page 81
▪
Install left portal drive, page 102
▪
Install right portal drive, page 116
2 M20 x 1.5
5870.350.110
Connection plat
e
▪
Dismantling left portal drive,
page 48
▪
Dismantle right portal drive,
page 58
▪
Assemble left portal drive,
page 88
▪
Assemble right portal drive,
page 103
1
AA02.041.051
Dr
iver tool
▪
Dismantling left portal drive,
page 48
▪
Assemble left portal drive,
page 88
▪
Assemble right portal drive,
page 103
1
AA01.311.408
R
apid grip
▪
Dismantling left portal drive,
page 48
1
Workshop Equipment
EN 4472.751.001 - 2015-11
19
