ZF AV 110 - Page 23

Figure Order no.
Designation
Chap
ter/section
Quantit
y
Comment
AA02.015.365
F
ixing spider
▪
Dismantle differential., page 68
1 Suitable for 5870.300.019
AA02.016.086
Plug inser
t
▪
Remove input, page 70
▪
Install input, page 74
▪
Install shaft seal onto the drive,
page 86
1
AA00.640.418
Suppor
t fixture
▪
Remove input, page 70
▪
Install input, page 74
▪
Install shaft seal onto the drive,
page 86
1
5870.203.002
P
ower screwdriver
▪
Remove input, page 70
▪
Install input, page 74
▪
Install shaft seal onto the drive,
page 86
1 Torque multiplier
Maximum output t
orque =
3600 Nm
5870.240.002
Loc
king mechanism
▪
Remove input, page 70
▪
Install shaft seal onto the drive,
page 86
1
