ZF AV 110 - Page 27

Figure Order no.
Designation
Chap
ter/section
Quantit
y
Comment
AA00.593.346
Scr
ewing device
▪
Assemble left portal drive,
page 88
1
M14 x 1.5
AA02.041.179
Dr
iver tool
▪
Assemble left portal drive,
page 88
▪
Assemble right portal drive,
page 103
1
5870.058.061
Dr
iver tool
▪
Assemble left portal drive,
page 88
▪
Assemble right portal drive,
page 103
1
5870.200.094
Measur
ing arbor
▪
Assemble left portal drive,
page 88
▪
Assemble right portal drive,
page 103
1
5870.700.004
Load cell
▪
Assemble lef
t portal drive,
page 88
▪
Assemble right portal drive,
page 103
1 Measuring range
1 to 60 kN
Workshop Equipment
EN 4472.751.001 - 2015-11
27
