ZF AV 110 - Page 54

20. Bolt in 5870.204.022 [Locating pin] at the
bear
ing bolt.
21. Force out and remove bearing bolt.
Fig. 66
22. Remove O‑rings (1).
Fig. 67
23. Hold shaft washer, axial roller cage and disk
(1).
24.
Push tapered roller bearing (2) and
intermediate gear outwards and remove the
releasing parts (1).
Fig. 68
Dismantling
54
EN 4472.751.001 - 2015-11
