2. Use 5870.240.002 [Locking mechanism] to
pull t
he input flange with a three-armed
puller from the pinion.
Fig. 113
3. Press screen sheet from the input flange.
Fig. 114
4. Use 5870.400.001 [Offset screwdriver] to
r
emove the shaft seal from the axle housing.
Fig. 115
Dismantling
EN 4472.751.001 - 2015-11
71
