5.2 Terminal compartment
Example: Position of terminals for devices with aluminum base plate
1 Line
2 Motor
3 Indication relays
4 Modulation
5 Jumper J1 for thermal protector TB/TP
6 Jumper E1.1/E1.2 for speed setting signal
Maximum cross sections of terminals for power section
Type
Line Motor
rigid flexible rigid flexible
F(S)DM2.5(A)M
4 mm
2
2.5 mm
2
4 mm
2
2.5 mm
2
F(S)DM5(A)M
4 mm
2
2.5 mm
2
4 mm
2
2.5 mm
2
F(S)DM8(A)M
4 mm
2
2.5 mm
2
4 mm
2
2.5 mm
2
F(S)DM10(A)M
4 mm
2
2.5 mm
2
4 mm
2
2.5 mm
2
F(S)DM16(A)M
4 mm
2
2.5 mm
2
4 mm
2
2.5 mm
2
F(S)DM22(A)M
6 mm
2
6 mm
2
6 mm
2
6 mm
2
F(S)DM32(A)M
16 mm
2
10 mm
2
10 mm
2
6 mm
2
F(S)DM40(A)M
25 mm
2
16 mm
2
16 mm
2
10 mm
2
F(S)DM50(A)M
25 mm
2
16 mm
2
16 mm
2
10 mm
2
Possible cross sections of terminals for control section
For all types
rigid flexible
Modulation 0.25 - 1.5 mm
2
0.25 - 1.5 mm
2
Indication relays 0.08 - 2.5 mm
2
0.08 - 2.5 mm
2
Operating Instructions Fcontrol Basic – model series FSDM2.5..50AM Electrical installation
L-BAL-E174-GB 1704 Index 005 Part.-No.
14/49
