Example: Programming “Controlmode”
|
0
|
to
|
1
|
in “Controller Setup”
1 2 3
4
5 6 7
0
Controlmode
P
« 0 »
Controlmode
▲
« 1 »
Controlmode
P
1
Controlmode
7 Start-up
7.1 Prerequisites for commissioning
Attention!
1. You must mount and connect the device in accordance with the operating instructions.
2. Double check that all connections are correct.
3. The mains voltage must match the information on the rating plate.
4. The rated current on the rating plate will not be exceeded.
5. Make sure that no persons or objects are in the hazardous area.
7.2 Procedure for commissioning
Sequence Setting
1
Check if Thermostats or Thermistors of the motor are connected to input “TB/TP In”.
If the motor protection function of the device is not neccesary the both terminals “TB / TP” have to be bridged.
2
Check if contact for enable is conected to “Digital In 1”.
If the device remote control is not required, the two terminals “D1 / 24V” must be bridged or alternatively the
function “Enable” deactivate
IO Setup.
3
Check connection and close housing carefully.
4
Turn on mains voltage.
5
If necessary, set the menu language in Menu group Start.
(Factory setting Englisch: “Language GB”)
6
The Motor Setup factory installed values are for variable voltage external rotor motors 400 V / 50 Hz. After
checking of the motor data the setting are to be adapted if necessary.
Motor rated voltage
(see Rating plate)
Setting
Edgefrequency
Setting
Max. Frequency
3 ~ 400 V, 50 Hz 48.5 Hz 50 Hz
3 ~ 400 V, 50/60 Hz 48.5 Hz 60 Hz
3 ~ 400 V, 60 Hz 57 Hz 60 Hz
Additional settings
Motor Setup.
Settings for U/f characteristic can only be made when no motor modulation is present!
" Switch off via a digital input for remote control (enable= OFF).
" Reduce speed setting signal or setting value to “0” with the display depending on the control mode.
Operating Instructions Fcontrol Basic – model series FSDM2.5..50AM Start-up
L-BAL-E174-GB 1704 Index 005 Part.-No.
