12 Enclosure
12.1 Technical data
Type
(Part-No.)
Rated current
Output
{1}
[A]
Rated current
(I fundamental
component @
50 Hz)
Input
{2}
[A]
Rated temper-
ature
[°C]
max. line fuse
{3}
[A]
max. heat dis-
sipation
{2}
[W]
Weight
[kg]
FSDM2.5AM
(308252)
2.5
2.5
(2.3)
40 6 50 2.9
FSDM5AM
(308240)
5.0
4.8
(4.5)
55 10 90 5.6
FSDM8AM
(308241)
8.0
7.1
(6.6)
40 10 140 6.5
FSDM10AM
(308260)
10.0
9.4
(8.6)
55 16 200 7.0
FSDM16AM
(308303)
16.0
15.2
(14,0)
40 20 360 7.2
FSDM22AM
(308315)
22.0
19.2
(17.7)
40 25 520 14.5
FSDM32AM
(308317)
32.0
27.6
(25.7)
50 35 700 29.6
FSDM40AM
(308319)
40.0
34.0
(31.5)
50 50 790 29.6
FSDM50AM
(308321)
50.0
47.5
(43.2)
50 63 910 32.8
{1} Rated current output
current indication rating plate @ rated voltage, @ rated temperature (cos φ 0.8 at the output).
{2} At rated voltage (cos φ 0.8 at the output), values for different specifications on request.
{3} Max. line fuse on site (line protection fuse) according to EN 60204-1 Classification VDE0113 Part 1
Line voltage* 3 ~ 208...480 V (-15 ... +10 %), 50/60 Hz
Nominal voltage 400 V
Maximal output voltage approx. 95 % from U
line
Switching frequency 16 kHz
Power factor > 0.9
Input resistance for speed setting
signal
for input 0...10 V: R
i
> 100 kΩ
for 0...20 mA input: R
i
= 100 Ω
Voltage supply for external devices +24 V ± 20 %, I
max
70 mA
Heat dissipation in standby opera-
tion
approx. 3 W
Output 10 V I
max
10 mA (short-circuit-proof)
Digital input “D1” Input resistance: R
i
approx. 4 kΩ
Voltage range high level: 10....30 V DC
Voltage range low level: 0....4 V DC
Max. contact rating of the relay 2 A / 250 V AC
Max. permissible ambient tempera-
ture for operation
55 °C
Min. permissible ambient tempera-
ture
0 °C (if mains voltage is not switched off up to -20 °C)
To avoid condensation the device must be continuously energized due to
the application of heat, with interruptions such that cooling to the point of
condensation does not occur.
Permissible temperature range for
storage and transport
-30...+80 °C (FSDM22: -30... +70 °C)
