Permissible installation height 0...4000 m amsl
≤ 1000 m: no limitation
> 1000 m: max. permissible output current = current indication name plate
minus 5 % / 1000 m
> 2000 m: max. permissible line voltage = max. voltage indication name
plate minus 1.29 % / 100 m
Permissible rel. humidity 85 % no condensation
Electromagnetic compatibility for the
standard voltage 230 / 400 V ac-
cording to DIN IEC 60038
Interference emission EN 61000-6-3 (domestic household applications)
Interference immunity EN 61000-6-2 (industrial applications)
Harmonics current According to EN 61000-3-2 (see Electrical installation / Harmonics current)
Please ask manufacturer for the individual harmonic oscillation levels of
the current as a percentage of the fundamental oscillation of the rated
current.
Max. leakage current according to
the defined networks of
DIN EN 60990
FSDM2.5/5/8AM < 3.5 mA
FSDM10/22/32/40/50AM > 3.5 mA
FSDM16AM (depending on applied mains voltage)
< 3.5 mA @ < 480 V
≥ 3.5 mA @ ≥ 480 V
Vibratory strength
(for vertical installation, i.e. cable
inlet down).
Broadband noise (simulated life-endurance test) in accordance with
EN 61373, category 1 class B.
Shock test according to EN 61373, category 1
Housing protection
IP54
* Regarding the mains connection, these devices are to be classified as category “C2” devices according to the relevant
DIN EN 61800-3. The increased requirements placed on electrical interference > 2 kHz for category “C1” devices are
complied with in addition.
12.1.1 Max. load dependent on ambient temperature and line voltage.
The maximum permissible temperature for the rated current at rated voltage is specified as rated
temperature.
Since the dissipation of the power loss (heat development) in the device is decisively dependent on
the ambient temperature, the max. load must be reduced at an ambient temperature above the rated
temperature (
following table)!
The average value measured during a 24 h period must be 5 K under the max. ambient temperature.
For installation in a switch cabinet, the device’s dissipation and its possible affect on the ambient
temperature must be taken into consideration!
Since the power loss in the device increases with rising line voltage, the following table must be
observed.
Maximal load depending on line voltage and ambient temperature
Type
208 V (-15 %)...415 V (+6 %)
over 415 V (+6 %)...480 V (+10 %)
40 °C 50 °C 55 °C
40 °C 50 °C 55 °C
F(S)DM2.5(A)M 2.5 A 2.2 A 2.0 A
2.5 A 1.8 A 1.6 A
F(S)DM5(A)M 5.0 A 5.0 A 5.0 A
5.0 A 5.0 A 5.0 A
F(S)DM8(A)M 8.0 A 7.0 A 6.5 A
8.0 A 6.5 A 6.0 A
F(S)DM10(A)M 10.0 A 10.0 A 10.0 A
10.0 A 10.0 A 10.0 A
F(S)DM16(A)M
16.0 A 13.0 A 12.0 A
14.5 A 12.5 A 11.5 A
FSDM22(A)M
22.0 A 18.0 A 15.3 A
22.0 A 17.0 A 14.5 A
FSDM32(A)M
32.0 A 32.0 A 30.0 A
32.0 A 32.0 A 30.0 A
FSDM40(A)M
40.0 A 40.0 A 37.0 A
40.0 A 40.0 A 35.0 A
FSDM50(A)M
50.0 A 50.0 A 48.0 A
50.0 A 50.0 A 46.0 A
