Display Code
Relay
K1
Explanation
Reaction of device
Adjustment
Line over-
voltage
13
de-energized, 13 -
14 interrupted
Line voltage too high
Line voltage above fixed limit for longer
than 75 s.
The modulation is switched off immedi-
ately at overvoltage, error message after
75 s.
Automatic switching back on and switch-
ing off of error message when the voltage
drops below the fixed limit for at least 15
s.
Check line voltage.
Peak current 14
de-energized, 13 -
14 interrupted
Error Peak current
If the output current increases above the
specified limit (even in a short time-
frame) the device will switch-off.
After a switch off the controller waits for
30 seconds then the controller attempt a
start.
If 10 switch offs take place consecutively
within 60 s (time to next respective error),
final switch off takes place with an error
message.
Should no further switch off be exceeded
in 90 sec. the counter will be reset.
Motor fault 15
de-energized, 13 -
14 interrupted
Motor fault
A connected thermostat or thermistor
has tripped the circuit or interruption be-
tween both terminals “TB / TP”.
Plug for “TP” or “TP” in wrong positions.
The unit cuts out and does not switch on
again.
Check motor and connection then reset
(
Motor protection).
Output filter 16
de-energized, 13 -
14 interrupted
Sine filter to hot
(only in version with integrated sine filter)
Switch off at to high temperature, restart-
ing after cooling down.
Check temperature in controller, Check
cooling of the controller.
Overload 17
de-energized, 13 -
14 interrupted
Overload fault
The controller was switched off by the
current limitation.
The error is set after detecting 4 times
(I
2
t-process; maximum overload applied
for 60 s).
After every detection (IGTB Recovery
Flag is set) there is a 30 s wait until a
new attempt is started.
The respective errors must alway have a
shorter interval than 5 minutes (started
after restart). The modulation is switched
off immediately after every detection.
Check load of the device.
Reset by enable or line voltage ON/OFF.
Operating Instructions Fcontrol Basic – model series FSDM2.5..50AM Events / Fault signals
L-BAL-E174-GB 1704 Index 005 Part.-No.
42/49
