ZIEHL-ABEGG Fcontrol Basic User Manual

Parameter Factory setting * User Setting Information
Motor Setup
MotorRatedCurr.
2.50 A
MotorRatedVolt.
400 V
Edgefrequency
48.5 Hz
Max. Frequency
50.0 Hz
Startvoltage
0 %
VF quadratic
ON
Rampup time
20 sec
Rampdown time
20 sec
Rotat. Direction
CW
Current limit
120 %
DC brake mode
0
DC brake time
10 sec
DC brake level
25 %
Motorheating
OFF
Overload detect.
OFF
Ripple compensation
OFF
Rampdown limit.
OFF
Suppression1
OFF
Range1 min.
10.0 Hz
Range1 max.
15.0 Hz
Suppression2
OFF
Range2 min.
20.0 Hz
Range2 max.
25.0 Hz
Suppression3
OFF
Range3 min.
30.0 Hz
Range3 max.
35.0 Hz
Diagnostic
IGBT temp. 32.0 °C
Capacitor 32.0 °C
MCU Temp. 32.0 °C
Output filter 27.3
E1 Input 0 %
DC-Voltage 565 V
Line voltage 330 V
Stateflags 1280
Faultflags 0
PIN-Accesslevel 2
* Specifications not binding, these values can differe depending on the software version and customer-specific pre-setting.
Operating Instructions Fcontrol Basic – model series FSDM2.5..50AM Parameter
L-BAL-E174-GB 1704 Index 005 Part.-No.
38/49
