H.264 Super Digital Video Recorder User Manual
23
the scan line . Click Stop button to stop.
4、Auto scan
In the horizontal line, set up a line, called linear sweep, PTZ repeated according to the route
setting operation.
1）
Line scan settings
Step1：In Picture 3.8, click Direction button to turn the PTZ to preset direction, then click Setup
button enter Picture 3.13, select the left boundary, return to Picture 3.8;
Step2 ： Please click direction arrows to adjust PTZ direction, click Setup button enter
Picture3.13, then select the right boundary, return to Picture 3.8;
Step3: Complete setup, that is the position of left and right boundary
Note: The left and right borders in the same horizontal line will be based on PTZ in the opposite
direction from the left border points along the border point of rotation to the right to carry out spin cycle;
Not in the same horizontal line around the border, PTZ is only connected with the left border
points, the level of trajectories as the right border of the end point in the opposite direction from the left
border points along the border point of rotation to the right to carry out spin cycle.
Picture 3.13 Border
2）
Line scan call
In Picture 3.8, click Page Switch button, then enter PTZ control menu as shown in Picture 3.10.
Please input the number of scan in the value blank , then click Scan button，PTZ begins to work on
the scan line . Click Stop button to stop.
5、Auto pan
Click Auto pan button, PTZ begins to rotate horizontally (relative to the original position of the
camera). Click the Stop button to stop.
Boundary
