CHAPTER 1 MAINTENANCE TESTS
1–4 www.zoll.com 9650-0309-01 Rev. E
2.0 Power Supply Test/Current
Equipment Needed
• Battery Current Test Fixture (P/N 9100-0690-TF),
• Power Supply 12V 10A,
• DMM (e.g. Agilent 34401A Digital Multimeter) or equivalent,
• AED PLUS, Quick-Test, Test Fixture (P/N 9100-0567-TF).
Setup
• Install the Battery Current Test Fixture (P/N 9100-0690-TF) into the battery well.
• On the DMM, set Function to DC Amps by pressing Shift button then the DC I button.
• Connect the RED lead from the I jack of the DMM to one of the Meter Leads on the Battery
Current Test Fixture (P/N 9100-0690-TF).
• Connect the BLACK lead from the LO jack (located above the I jack) of the DMM to the
other Meter Leads on the Battery Current Test Fixture (P/N 9100-0690-TF).
• Connect the power supply RED and BLACK leads, respectively into the Power Supply
posts on the Battery Current Test Fixture (P/N 9100-0690-TF).
• Connect AED PLUS Quick-Test Test Fixture (P/N 9100-0567-TF) to the unit.
• Set the Power Supply to 12.00V.
Test Action Expected Result(s) Pass Fail
2.1
Turn the Power Supply on.
Verify the unit issues a voice
and text prompt UNIT OK, and
the unit is turned off.
 
2.2
Press the I Measure switch on
the Battery Current Test Fixture.
Observe the current
measurement on the Digital
Multimeter is between 10uA to
70uA.
 
2.3
Press and release the On/Off
button.
Verify that the unit powers on in
rescue mode. Wait for the
following prompts are given:
ADULT PADS, DONT’T TOUCH
PATIENT ANALYZING... before
taking measurement.
 
2.4
Press the I Measure switch on
the Battery Current Test Fixture.
Observe the current
measurement on the Digital
Multimeter is between 0.1A to
0.4A.
 
2.5 Press and hold the On/Off
button to power off the unit.
Verify unit displays UNIT
POWERING OFF message.
 
