CHAPTER 1 MAINTENANCE TESTS
1–22 www.zoll.com 9650-0309-01 Rev. E
15.0 Read Error Log - Final
Equipment Needed
• Power Supply 12V 10A,
• Battery Current Test Fixture (P/N 9100-0690-TF) or AED PRO Disposable Battery (P/N
1008-002003-01),
• AED PLUS Quick-Test Test Fixture (P/N 9100-0567-TF),
Setup:
• Start the ZAS on the computer; make sure the connection is established before starting the
AED Pro unit.
• Note: For best transmission results, the ZOLL USB IrDA port (P/N 9355-0807) must be
facing the IrDa port of the unit with a clear 10 to 18-inch line-of-sight.
• Connect AED PLUS Quick-Test Test Fixture (P/N 9100-0567-TF) to the unit.
Test Action Expected Result(s) Pass Fail
15.1
If the unit is on, press the On/Of
button for 1 second to turn off
the unit. .
Unit powers off.
 
15.2
Press and hold the On/Off
button for at least 7 seconds,
then release it.
The AED Pro unit establishes
contact with the Computer
within 5 seconds and the unit
issues the voice and text prompt
message UNIT OK, followed
by NONRESCUE MODE and
COMMUNICATION
ESTABLISHED
 
15.3
Double click on the latest ZAS
AED Pro version software icon
on Desktop.
Click on History and select
“upload and display history data
from device”.
Click NEXT and notice “*.CEH
“ in the filename box and click
SAVE.
Click on the ERROR LOG box.
Verify ERROR ID codes and
ERROR DESCRIPTIONS.
 
15.4
Clear Log and Close the AED
Pro Error Log box.
 
