CHAPTER 1 MAINTENANCE TESTS
1–6 www.zoll.com 9650-0309-01 Rev. E
4.0 Pediatric Mode/Electrode Connector Type Test
Equipment Needed:
• Power Supply 12V 10A,
• Battery Current Test Fixture (P/N 9100-0690-TF) or AED PRO Disposable Battery (P/N
1008-002003-01) or SurePower Rechargeable Li-Ion Battery (P/N 1009-001535-03),
• AED PLUS, Quick-Test, Test Fixture (P/N 9100-0567-TF),
• Defibrillator Analyzer (e.g. QED-6 or Impulse 4000) or equivalent.
Setup:
• Connect the HV Connector Cable of the AED PLUS Quick-Test Test Fixture (P/N
9100-0567-TF) to the Defibrillator Analyzer and set waveform to VFIB.
• Set the AED PLUS Quick-Test Test Fixture (P/N 9100-0567-TF) to Pediatric Mode.
• Set the Power Supply to 12.00V then turn it off.
Note: Test values below are based on the default pediatric energy settings (50, 70, and 85
Joules) into a 50 ohm load.
Test Action Expected Result(s) Pass Fail
4.1
Connect the Simulator Cable to
the device, and then turn the
Power Supply on.
Verify the unit issues a voice
and text prompt UNIT OK,
 
4.2
Press the On/Off button and
release it.
Verify that the following
prompts are given:
PEDIATRIC PADS, DON’T
TOUCH PATIENT
ANALYZING, followed by
SHOCK ADVISED, DON’T
TOUCH PATIENT, and
PRESS FLASHING SHOCK
BUTTON.
 
4.3
Press Flashing Shock button. Verify that unit prompts
SHOCK DELIVERED.
 
4.4
1
st
shock energy test (default
value 50 joules).
Verify the Energy delivered into
analyzer is 43 joules to 59
joules.
 
4.5
Press and hold the On/Off
button to power off the unit.
Verify unit displays UNIT
POWERING OFF message.
 
