9650-0309-01 Rev. E ZOLL AED Pro Service Manual 1–9
6.0 Battery Type Test
Equipment Needed:
• SurePower Rechargeable Li-Ion Battery (P/N 1009-001535-03),
• AED PRO Disposable Battery (P/N 1008-002003-01),
• AED PLUS, Quick-Test, Test Fixture (P/N 9100-0567-TF),
• Defibrillator Analyzer (e.g. QED-6 or Impulse 4000) or equivalent.
Setup:
• Connect the HV Connector Cable of the AED PLUS Quick-Test Test Fixture (P/N
9100-0567-TF) to the Defibrillator Analyzer.
• Connect AED PLUS Quick-Test Test Fixture (P/N 9100-0567-TF) to the unit.
Test Action Expected Result(s) Pass Fail
6.1
Insert the SurePower
Rechargeable Li-Ion Battery
into the device (battery well).
Verify BATTERY
INSERTION TEST appears on
the display screen of the device.
 
6.2
Verify the unit issues a voice
and text prompt UNIT OK and
the Green Check symbol is
displayed in the Ready Indicator
before unit shuts off by itself.
 
6.3
Remove Battery. Verify the Green Check
switches to a Red X symbol in
the Ready Indicator.
 
6.4
Insert the AED PRO Disposable
Battery into the device (well).
Verify BATTERY
INSERTION TEST appears on
the display screen of the device.
 
6.5
Verify the unit issues a voice
and text prompt: IF NEW
BATTERY PRESS LEFT
SOFT KEY and the Green
Check symbol is displayed in
the Ready Indicator, followed
by UNIT OK after 20 seconds
before unit shuts off by itself.
 
6.6
Remove Battery. Verify the Green Check
switches to a Red X symbol in
the Ready Indicator.
 
