9650-0309-01 Rev. E ZOLL AED Pro Service Manual 1–13
9.0 Patient Impedance Calibration
Equipment Needed
• Power Supply 12V 10A,
• Battery Current Test Fixture (P/N 9100-0690-TF) or AED PRO Disposable Battery (P/N
1008-002003-01),
• AED PLUS Quick-Test Test Fixture (P/N 9100-0567-TF),
• PC with AED PLUS/PRO DCI Panel software (P/N 9103-0815-SW),
• AED PRO Resistance, Decade Box (P/N 9100-000957-TF) or equivalent (e.g.RS-200
Resistance Substituter).
Setup:
• Power up with IrDA Mode (communication mode).
• Note: For best transmission results, the ZOLL USB IrDA port (P/N 9355-0807) must be
facing the IrDa port of the unit with a clear 10 to 18-inch line-of-sight.
• Note: Patient Impedance and ECG Calibration are saved together. To test calibration of both
Impedance and ECG offset, select DCI commands: GICAL; GEVOL, 2000; GECAL.
• Connect AED PLUS Quick-Test Test Fixture (P/N 9100-0567-TF) to the unit.
• Connect the Decade Box to the HV Connector Cable of the AED PLUS Quick-Test Test
Fixture (P/N 9100-0567-TF) to set the appropriate resistance for Impedance calibration. The
decade box can only handle ¼ watt, DO NOT discharge into the box.
Test Action Expected Result(s) Pass Fail
9.1
Double click on DCI_Panel icon
on Desktop. Select AED Pro
mode.
Verify the DCI Panel.vi appear
screen is displayed.
 
9.2
Set Decade Box to 10 Ohms.
Select SIL (hi, lo, md) from the
‘Command 1’ window, enter
LO in ‘Parm 1 (val)’ window
and click SEND.
The response will be OK.
 
9.3
Set Decade Box to 35 Ohms.
Select SIL (hi, lo, md) from the
‘Command 1’ window, enter
MD in ‘Parm 1 (val)’ window
and click SEND.
The response will be OK.
 
9.4
Set Decade Box to 300 Ohms.
Select SIL (hi, lo, md) from the
‘Command 1’ window, enter HI
in ‘Parm 1 (val)’ window and
click SEND.
The response will be OK.
 
