8.0 Internal Discharge Test
Equipment Needed
• Power Supply 12V 10A,
• Battery Current Test Fixture (P/N 9100-0690-TF) or AED PRO Disposable Battery (P/N
1008-002003-01),
• AED PLUS Quick-Test Test Fixture (P/N 9100-0567-TF),
• Defibrillator Analyzer (e.g. QED-6 or Impulse 4000) or equivalent.
Setup:
• Connect the HV Connector Cable of the AED PLUS Quick-Test Test Fixture (P/N
9100-0567-TF) to the Defibrillator Analyzer and set waveform to VFIB.
• Connect AED PLUS Quick-Test Test Fixture (P/N 9100-0567-TF) to the unit.
Test Action Expected Result(s) Pass Fail
8.1
Disconnect the Simulator Cable
from the device, and then turn
the Power Supply on.
Verify that the following prompt
is given: PLUG IN CABLE.
 
8.2
Re-connect the Simulator Cable
to the device.
Verify that unit voice prompts,
ADULT PADS, followed by
UNIT OK before unit shuts off
by itself.
 
8.3
Press the On/Off button and
release it.
Verify that the following
prompts are given: ADULT
PADS, DON’T TOUCH
PATIENT ANALYZING,
followed by SHOCK
ADVISED, DON’T TOUCH
PATIENT, PRESS
FLASHING SHOCK
BUTTON
 
8.4
DO NOT press Flashing Shock
button.
Verify the ready beep stays
steady for 3 seconds
approximately and voice
prompts again DON’T TOUCH
PATIENT, PRESS
FLASHING SHOCK
BUTTON
 
8.5
Verify the ready beep stays
steady for 3 seconds
approximately and voice
prompts again DON’T TOUCH
PATIENT, PRESS
FLASHING SHOCK
BUTTON, followed by 2 beeps
 
