10.0 ECG Lead-Off Detection
Equipment Needed
• Power Supply 12V 10A,
• Battery Current Test Fixture (P/N 9100-0690-TF) or AED PRO Disposable Battery (P/N
1008-002003-01),
• Defibrillator Analyzer (e.g. QED-6 or Impulse 4000) or equivalent,
• AED PRO 3-Lead ECG Cable (PN 9500-001802) or (8000-0838).
Setup:
• Insert the AED PRO 3-Lead ECG Cable into the connector on the AED Pro unit and connect
the leads to the Defibrillator Analyzer.
• Set the Defibrillator Analyzer to NSR (normal sinus rhythm).
• Place the Battery Current Test Fixture in the battery well.
• Set the Power Supply to 12.00V.
Test Action Expected Result(s) Pass Fail
10.1
Turn on the Power Supply. Verify the unit issues a voice
and text prompt UNIT OK
before unit shuts off by itself.
 
10.2
Turn on the AED Pro unit. Verify the rhythm is displayed
and the unit issues a voice and
text prompt ECG
MONITORING CABLE.
 
10.3
Pull any of the ECG leads from
the Analyzer.
Verify that the signal disappears
and the unit issues a voice and
text prompt CHECK ECG
ELECTRODES
 
10.4
Press and hold the On/Off
button to power off the unit.
Unit powers off.
 
