CHAPTER 1 MAINTENANCE TESTS
1–16 www.zoll.com 9650-0309-01 Rev. E
11.0 ECG Offset Calibration
Equipment Needed
• Power Supply 12V 10A.
• Battery Current Test Fixture (PN 9100-0690-TF) or Disposable Battery (PN
1008-002003-01),
• AED PLUS Quick-Test Fixture (PN 9100-0567-TF),
• Defibrillator Analyzer(e.g QED-6 or Impulse 4000) or equivalent,
• PC with AED PLUS/PRO DCI Panel software (PN 9103-0815-SW).
Setup:
• Power up with IrDA Mode (communication mode).
• Note: For best transmission results, the ZOLL USB IrDA port (P/N 9355-0807) must be
facing the IrDa port of the unit with a clear 10 to 18-inch line-of-sight.
• Connect AED PLUS Quick-Test Test Fixture (P/N 9100-0567-TF) to the unit.
• Connect AED PLUS Quick-Test Test Fixture (P/N 9100-0567-TF) to the Defibrillator
Analyzer.
Test Action Expected Result(s) Pass Fail
11.1
Set the QED 6 as follow:
Select: WAVE , select PERF
Select “+” sign 2 times.
The QED 6 will display the
following:
Performance 10Hz Sin
 
11.2
Select from the DCI commander
1:
GEVOL Enter 2000 in 'Parm 1
(val)' window, Select from the
DCI Commander 2: GECAL
(Get ECG Voltage offset level
for 2000mS) Click on "Send"
The response will be:
GEVOL,XX(VOL) GECAL, XX.
This is the current setting of the
offset
 
