Defibrillator Energy Test
9650-0309-01 Rev. E ZOLL AED Pro Service Manual 1–7
5.0 Defibrillator Energy Test
Equipment Needed:
• Power Supply 12V 10A, Battery Current Test Fixture (P/N 9100-0690-TF) or AED PRO
Disposable Battery (P/N 1008-002003-01),
• AED PLUS Quick-Test Test Fixture (P/N 9100-0567-TF),
• Defibrillator Analyzer (e.g. QED-6 or Impulse 4000) or equivalent.
Setup:
• Connect the HV Connector Cable of the AED PLUS Quick-Test Test Fixture (P/N
9100-0567-TF) to the Defibrillator Analyzer.
• Set the AED PLUS Quick-Test Test Fixture (P/N 9100-0567-TF) to Defib Mode.
• Set the Power Supply to 12.00V.
Note: Test values below are based of the default adult energy settings (120, 150,
and 200 Joules) into a 50 ohm load.
Test Action Expected Result(s) Pass Fail
5.1
Disconnect the Simulator Cable
from the device, and then turn
the Power Supply on.
Verify that the following
prompts are given: PLUG IN
CABLE, PLUG IN CABLE.
 
5.2
Re-connect the Simulator Cable
to the device.
Verify that unit voice prompts
ADULT PAD followed by
UNIT OK before unit shuts off
by itself.
 
5.3
Press the On/Off button and
release it.
Verify that the following
prompts are given: ADULT
PADS, DON’T TOUCH
PATIENT ANALYZING,
followed by “SHOCK
ADVISED, “DON’T TOUCH
PATIENT, PRESS
FLASHING SHOCK
BUTTON.
 
5.4
Press Flashing Shock button Verify that unit prompts
SHOCK DELIVERED.
 
5.5
1
st
shock energy test (default
value 120 joules)
Verify the Energy delivered into
analyzer is 105 joules to 143
joules.
 
5.6
Verify the unit prompts START
CPR followed by CONTINUE
CPR.
 
