CHAPTER 1 MAINTENANCE TESTS
1–20 www.zoll.com 9650-0309-01 Rev. E
13.0 Write Calibration to Flash
Equipment Needed
• Power Supply 12V 10A,
• Battery Current Test Fixture (P/N 9100-0690-TF) or AED PRO Disposable Battery (P/N
1008-002003-01),
• USB Flash Drive (P/N 8000-000474),
• AED PLUS, Quick-Test, Test Fixture (P/N 9100-0567-TF).
Setup:
• Connect AED PLUS Quick-Test Test Fixture (P/N 9100-0567-TF) to the unit.
• Place the in the battery well.
• Set the Power Supply to 12.00V.
• Turn on the Power Supply and turn the unit off.
Note: To download data to a USB device in the AED pro, make sure you are in
Non-Rescue Mode.
Test Action Expected Result(s) Pass Fail
13.1
Press and hold the On/Off
button for at least 7 seconds,
then release it.
Verify the unit issues a voice
and text prompt UNIT OK,
 
13.2
Attach a USB device to the port
inside the battery compartment,
and then press the USB softkey.
 
13.3
Press the ALL softkey to
download all patient data on the
unit.
Verify the unit issues a voice
and text prompt USB DEVICE
CONNECTED, followed by
DOWNLOADING DATA and
DATA DOWNLOAD
COMPLETE
 
13.4
If there is no USB device
attached or if the unit fails to
establish a connection with the
device, the unit issues command
INSERT USB DEVICE.
 
